The regulator every ESP32 secretly needs

A 3.3V supply for an ESP32: an LD1117 regulator with enough capacitance to ride out the radio's current spikes, plus a power LED.

Power

Component side layout of The regulator every ESP32 secretly needs on a perfboard 16 by 28 holes — 16 × 28 holes · 8 parts · 12 wiresOpen the build sheet

Free build sheet

The parts, every wire with its length and bend points, a bend guide, both sides of the board and checkboxes to track your progress. Print it or keep it open at the bench.

Open the build sheet

What you need

8 parts on a perfboard 16 × 28 holes, plus hookup wire.

Qty	Part	Where to buy
2	Electrolytic Cap10uF C1, C2	Buy Electrolytic Cap on Amazon
1	Ceramic Cap100nF C3	Buy Ceramic Cap on Amazon
1	Power Input (2-pin) J1
1	Signal+Power Header (3-pin) J2
1	LED LED1	Buy LED on Amazon
1	TO-220 Q1
1	Resistor (axial)330 R1	Buy Resistor (axial) on Amazon

Check every pin against the datasheet of the exact part in your hands before wiring.

As an Amazon Associate I earn from qualifying purchases.

Cut list

12 wires, 305 mm (12.0 in) in total, in the order the build sheet cuts them. Wire numbers match the build sheet. Each length includes 5 mm per end to go through the hole.

Wire	Colour and net	Route	Length	Bends
12	BlackGND J26 → D24	J26 → D24	30mm	20mm (90°)
6	Black3V3 I15 → H25	I15 → H25	38mm	8mm (90°)
5	Blue3V3 J16 → L16	J16 → L16	15mm	Straight
11	BlueGND I18 → J24	I18 → J24	28mm	20mm (90°)
10	GreenGND J17 → L17	J17 → L17	15mm	Straight
4	Green3V3 E16 → H16	E16 → H16	18mm	Straight
7	RedGND E5 → I5	E5 → I5	20mm	Straight
1	Red5V D3 → J3	D3 → J3	25mm	Straight
3	White3V3 C16 → C11	C16 → C11	23mm	Straight
9	WhiteGND E10 → H17	E10 → H17	35mm	23mm (90°)
8	YellowGND F4 → D9	F4 → D9	28mm	18mm (90°)
2	Yellow5V C4 → C12	C4 → C12	30mm	Straight

About this build

An ESP32 runs on 3.3V, not 5V, and it pulls sharp current spikes every time the radio transmits. So it needs a 3.3V supply with real capacitance on both sides of the regulator.

This board is an LD1117V33 in a TO-220. 5V comes in on a 2 pin input with a 10uF cap, and the 3.3V output gets a 10uF and a 100nF. A 330 ohm resistor and an LED show when the output is up, and a 3 pin header carries 3.3V and ground out to the ESP32.

One trap: the LD1117 doesn't share the 7805's lead order, so you can't drop one into the other's footprint. The build sheet and the ST datasheet give the wiring.
